Flexible connection made of Ø 8 mm annealed copper tube, chemically nickel-plated, used for High Pressure connection of the manifold to the inlet of the device downstream or of two manifolds; the connection nuts are also chemically nickel-plated CW614 brass, with a specific thread for the type of gas.
Nickel-plated copper pipe with Ø 8 mm external diameter, Ø 4 mm internal, length 800 mm.
Inlet and outlet fittings made of nickel-plated brass, with a specific thread for the type of gas.
SILICONE O-Ring with a 90 Shore degree of hardness for Oxygen.
EPDM PEROX O-Ring for Carbon Dioxide.
NYLON gasket for compressed Air for medical use, Nitrous Oxide and Nitrogen.
